Description

Technical Specification Performance parameter Light source type: Red LED aiming light, white LED illumination light Decoding ability: 1D: Code128, Code39, Code39 Full Ascii, Code93, Code11, Code32, Codebar, UPCA, UPCE, EAN8, EAN13, Interleaved 2 of 5, Matrix 2 of 5, IATA 2 of 5, Industrial 2 of 5, MSI 2D: QR Code, Data Matrix, PDF417, Micro QR, Micro PDF417, Aztec Scan type: CMOS Resolution: 640×480 Scan mode: Manual mode/Continuous mode/Automaitc mode Scan angle: Elevation ± 60°, Rotation 360°, Yaw ± 60° Precision: ≥4mil Depth of field: 30-280mm(EAN13,13mil) Printing contrast: ≥20% Error：1/5million Prompt mothod：Buzzer, LED, Vibration Screen display: 1.44-inch LED screen + button (display: wireless connection, battery level, time，calculate，store) Wireless parmeter Wireless communication: 2.4G+Bluetooth Transmission distance: Open Area: 80 meters(2.4G); 50 meters(Bluetooth) Storage mode: Timely mode, inventory storage mode, (Storage capacity of 350000 characters) Pairing mode: Receiver: One-to-one Interface: USB-HID, USB-COM Environmental parameter Working temperature: -10°C~60°C Storage temperature: -20°C~70°C Humidity: 5%~95% RH （No condensation) Shock resistance: Passed 1.5meters drop test Physical parameter Weight: 378g Dimension: Scanner: 114.3mm×65.8mm×150.7mm; Base: 209.2mm×76.7mm×58.2mm Material quality: ABS+PC Cable length: 1m Electrical Parameter Voltage: DC5V±5% Current: 220mA Battery capacity: 2200mAh Charging time: 4h Working hours: 5.5h Charging method: Magnetic charging base, Type-C
