Description

Dual-motor gear driver design
300 meters ribbon capacity
Head-up sensor and platen replacement
200 MHz 32-bit processor with 16MB SDRAM,16MB flash memory

• • Resolution: 203 DPI (8 dots/mm)
  • Print Method: Thermal Transfer / Direct Thermal
  • Max. Print Speed: Up to 127 mm/s (5 inches per second)
  • Max. Print Width: 104 mm (4.09 inches)
  • Max. Print Length: 1,778 mm (70 inches)
  • Processor: 32-bit RISC CPU
  • Memory: 8 MB Flash, 8 MB SDRAM (Some variations feature standard MicroSD card expansion up to 4GB)
  • Media Sensors: Movable Gap Sensor & Movable Black Mark Sensor
  • Printer Emulation Languages: TSPL, ZPL, EPL, DPL

• • Media Width: 25.4 mm to 118 mm (1.0″ to 4.6″)
  • Media Thickness: 0.06 mm to 0.254 mm (2.36 to 10 mil)
  • Media Roll Capacity: Up to 127 mm (5″) Outer Diameter
  • Media Core Diameter: 25.4 mm to 76.2 mm (1″ to 3″)
  • Ribbon Capacity: Max length of 300 meters
  • Ribbon Core Inner Diameter: 25.4 mm (1 inch)
  • Ribbon Width: 40 mm to 110 mm (1.6″ to 4.3″)
  • Media Types Compatible: Continuous, gap, black mark, fan-fold, and punched hol

• • Standard Interfaces: USB 2.0
  • Optional Interfaces: Serial, Ethernet (LAN), Wi-Fi, and Bluetooth
  • Supported OS Drivers: Windows, Linux, macOS, Android, and Chrome OS
  • Bundled Software: BarTender UltraLite / Mobile Label Design Apps

• Enclosure Material: ABS Plastic
• Dimensions: 299 mm × 235 mm × 198.3 mm
• Weight: 2.55 kg – 2.57 kg
• Printhead Life: Standard rating up to 30 km
