Processor
Intel® Core™ i9-14900HX, 24C ORE(8P + 16E) / 32T, P-core 2.2 / 5.8GHz, E-core 1.6 / 4.1GHz, 36MB
AI PC Category
AI-Powered Gaming PC
Graphics
NVIDIA® GeForce RTX™ 4070 8GB GDDR6, Boost Clock 2175MHz, TGP 140W, 321 AI TOPS
Chipset
Intel® HM770 Chipset
Memory
2x 8GB SO-DIMM DDR5-5600
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR5-5600
Storage
1TB SSD M.2 2280 PCIe® 4.0×4 NVMe®
Storage Support
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Card Reader
microSD Card Reader
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera
FHD 1080p with E-shutter
Microphone
2x, Array
Battery
Integrated 80Wh
Power Adapter
230W Slim Tip (3-pin)
Special Features
AI Chip: LA1
LENOVO LEGION 5 DESIGN
Display
16″ WQXGA (2560×1600) IPS 350nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision®, G-SYNC®, Low Blue Light
Touchscreen
None
Color Calibration
Factory Color Calibration
Keyboard
4-Zone RGB Backlit, English (US)
Touchpad
Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
Case Color
Luna Grey
Surface Treatment
Aluminium Stamping (Anodized with Sandblasting)
Case Material
Aluminium (Top), PC-ABS (Bottom)
Dimensions (WxDxH)
359.7 x 262.3 x 19.7-25.2 mm (14.16 x 10.33 x 0.78-0.99 inches)
Weight
Around 2.36 kg (5.2 lbs)
LENOVO LEGION 5 SOFTWARE
Operating System
Windows® 11 Home, English
Bundled Software
Office Trial
CONNECTIVITY
Ethernet
100/1000M (RJ-45)
WLAN + Bluetooth
Wi-Fi® 6E, 802.11ax 2×2 + BT5.2
Standard Ports
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Card reader
1x Power connector
LENOVO LEGION 5 SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
LENOVO LEGION 5 CERTIFICATIONS
Green Certifications
ErP Lot 6
ErP Lot 26
RoHS compliant
Other Certifications
TÜV Rheinland® Low Blue Light (Hardware Solution)

1 YEAR WARRANTY
