Description

LENOVO ThinkPad P16 Gen 2  WORKSTATION INTEL i9-13950HX 32GB 1TB 16″ 2.5K 165HZ 8GB RTX2000 W11P

Intel Core i9-13950HX, 24Core (8P + 16E) / 32T, P-core 2.2 / 5.5GHz, E-core 1.6 / 4.0GHz, 36MB Intel Smart Cache
2x 16GB SODIMM DDR5-5600 Non-ECC
1TB SSD M.2 2280 PCIe 4.0×4 Performance NVMe Opal 2.0
NVIDIA RTX 2000 Ada Generation 8GB GDDR6
Windows 11 Pro, English

PERFORMANCE
Processor
Intel® Core i9-13950HX, 24C (8P + 16E) / 32T, P-core 2.2 / 5.5GHz, E-core 1.6 / 4.0GHz, 36MB Intel Smart Cache
AI PC Category
AI-Ready Workstations
Graphics
NVIDIA® RTX 2000 Ada Generation 8GB GDDR6
Chipset
Intel® WM790 Chipset
Memory
2x 16GB SODIMM DDR5-5600 Non-ECC
Memory Slots
Four DDR5 SODIMM slots, dual-channel capable
Max Memory
Models with Non-ECC memory: Up to 192GB (4x 48GB SODIMM DDR5-5600 Non-ECC)
Storage
1TB SSD M.2 2280 PCIe® 4.0×4 Performance NVMe® Opal 2.0
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 8TB, 4TB each
• RAID 0/1 support
RAID Preset
None
Card Reader
SD 7.0 Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3306 codec
Speakers
Stereo speakers, 2W x2, Dolby Atmos®
Microphone
2x, Array
Camera
FHD 1080p + IR Hybrid with Privacy Shutter and Human Presence Detection
Battery
94Wh
Power Adapter
170W Slim Tip (3-pin)
DESIGN
Display
16″ WQXGA (2560×1600) IPS 500nits Anti-glare, 100% sRGB, 165Hz, Eyesafe®
Touchscreen
None
Color Calibration
Factory Color Calibration
Pen
Pen Not Supported
Keyboard
Backlit, English
Dimensions (WxDxH)
364 x 266 x 30.23 mm (14.3 x 10.5 x 1.2 inches)
Weight
Starting at 2.95 kg (6.5 lbs)
Case Color
Storm Grey (Top), Villi Black (Bottom)
Case Material
Aluminium (Top), PPS + 50% GF (Bottom)
SOFTWARE
Operating System
Windows® 11 Pro, English
Bundled Software
None
CONNECTIVITY
WLAN + Bluetooth
Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 + BT5.3, vPro®
WWAN
WWAN Upgradable to 4G
SIM Card
No physical SIM card inbox
Ethernet
No Onboard Ethernet
NFC
No NFC
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0
2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer and DisplayPort™ 1.4)
1x HDMI® 2.1, up to 8K/60Hz or 4K/240Hz (models with discrete graphics)
1x Headphone / microphone combo jack (3.5mm)
1x SD Express 7.0 card reader
Optional Ports (configured)
1x Nano-SIM Card Slot
Docking
Various docking solutions supported via Thunderbolt™ or USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® P16 Gen 2
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington® Nano Security Slot, 2.5 x 6 mm
Smart Card Reader
No Smart Card Reader
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Other Security
Bottom cover tamper detection
Camera privacy shutter (camera models)
Ultrasonic Human Presence Detection for IR camera
IR camera for Windows® Hello (facial recognition)
