Description
Xprinter XP-TT424B is a 4-inch desktop barcode and label printer supporting both direct thermal and thermal transfer printing
- Printing Method: Direct Thermal / Thermal Transfer
- Resolution: 203 DPI (8 dots/mm)
- Max. Print Speed: Up to 127 mm/s (5 in/s)
- Max. Print Width: 108 mm (4.25 in)
- Max. Print Length: Up to 1778 mm
- Memory: 8MB SDRAM, 8MB Flash (expandable via MicroSD up to 4GB)
- Media Types: Continuous, gap, black mark, fan-fold, and perforated media
- Media Width: 25.4 mm to 118 mm
- Media Thickness: 0.06 mm to 0.254 mm
- Ribbon Capacity: Max. 90m length (width matching media)
- Sensors: Gap, cover opening (head-up), black mark, and ribbon sensors
- Interface: Standard USB 2.0 (Optional: Wi-Fi, Bluetooth, TF card, or Ethernet depending on configuration)
- Emulation / Command Sets: TSPL, ZPL, EPL, DPL
- Design & Build: Double-walled clamshell design with a visual paper bin
- Standard Built-in Interfaces: USB 2.0 and LAN/Ethernet [1, 2,
- Optional Wireless Add-ons: Bluetooth and Wi-Fi (depending on the specific configuration or regional model)
- Print Resolution & Speed: 203 DPI at up to 127 mm/s (5 inches per second)
- Printing Technology: Dual-mode support for both Direct Thermal and Thermal Transfer printing
- Dimensions: 246 x 199 x 168 mm
- Power Supply: AC 100–240V input, DC 24V 2.5A output
- Certifications: CCC, CE, FCC, RoHS, KC, SAA, BIS, BSMI
Label Longevity Long-lasting / Permanent. Resistant to fading, sunlight, scratching, chemicals, and heat (ideal for product tags or asset tracking).
